Item NO.: | SR(365-390)-120M6-H |
Product Origin: | China |
Color: | Black, silver, full black |
Lead Time: | 7-10 days |
Order(MOQ): | 31 pcs per pallet |
Module Dimension: | 1755*1038*35mm |
Warranty: | 30 Years Warranty |
Certificate: | TUV, CE, ISO, ETL, CQC |
Sunry monocrystalline solar panel ensures higher module efficiency and higher power output. Max. efficiency reaches to 21.41%.
Sunry solar photovoltaic modules are designed for large electrical power requirements. With 25 years warranty, PERC offers high power, reliable performance for both on-grid and off-grid solar projects.
Electrical Characteristics At Standard Test Conditions (STC) | ||||||
Module | SR(365-390)-120M6-H | |||||
Encapsulation | Glass/EVA/Cell/EVA/Backsheet | |||||
Max. Power (W) | 365 | 370 | 375 | 380 | 385 | 390 |
Max. Power Voltage (Vmp/V) | 34.0 | 34.2 | 34.4 | 34.6 | 34.8 | 35 |
Max. Power Current (Imp/A) | 10.74 | 10.82 | 10.90 | 10.98 | 11.06 | 11.14 |
Open Circuit Voltage (Voc/V) | 40.8 | 41.04 | 41.3 | 41.52 | 41.8 | 42.0 |
Short Circuit Current (Isc/A) | 11.3 | 11.41 | 11.5 | 11.58 | 11.67 | 11.76 |
Module Efficiency (%) | 20.04 | 20.31 | 20.59 | 20.86 | 21.13 | 21.41 |
Power Tolerance (W) | 0~+5W | |||||
Temperature Coefficient of Isc | 0.05%/°C | |||||
Temperature Coefficient of Voc | -0.31%/°C | |||||
Temperature Coefficient of Pmax | -0.35%/°C | |||||
STC | Irradiance 100w/m2, Cell Temperature 25℃, Air Mass 1.5 |
Product Weight: | 20kg | Packing: | 31pcs/pallet, 858pcs/40HQ |
Pallet dimension: | 1790*1100*1180mm | Pallet weight: | 660kg |
DC or AC Solar Energy System
Welcome to contact us for the assistance of an expert to start your own solar projects!
